Makita PT354DZ 12V Max Pin Nailer 23G – Body Only

Makita PT354DZ 12V Max Pin Nailer 23G – Body Only

Stock Code: PT354DZ
Available to Order
£337.20 (inc VAT) per each
£281.00 (exc VAT)
Quantity: - +

Makita PT354DZ 12V Max CXT Pin Nailer 23G – Body Only

The Makita PT354DZ is a compact and cordless 23-gauge pin nailer, engineered for delicate trim work, mouldings, cabinetry, and craft applications. Designed for clean, near-invisible fastening, it drives 23Ga headless pins (18–35mm) with precision and consistency — ideal for professionals who demand cordless flexibility without sacrificing finish quality.


Powered by the Makita 12V Max CXT platform, this tool features tool-less depth adjustment, anti-dry fire mechanism, and double trigger operation for enhanced safety and user control. A built-in LED light and nose-mounted workpiece contact tip ensure clear visibility and precise placement.


✅ Key Benefits:

  • Body only – battery and charger sold separately

  • Compatible with 23-gauge headless pins (18–35mm) – ideal for fine finishing

  • Cordless operation – no compressor or hose needed

  • Tool-less depth adjustment – set nail depth quickly and easily

  • Anti-dry fire mechanism – protects the tool and surface

  • Double trigger safety – prevents accidental firing

  • LED job light – for improved visibility in tight or dark areas

  • Narrow nose design – provides excellent line of sight for accurate placement

  • Belt clip included – for easy tool access during work

  • Part of the Makita 12V Max CXT range


⚠️ Please Note:
This is a body-only model. Battery and charger are not included. Use only compatible 23-gauge headless pins. Always wear appropriate PPE.

BrandMakita
Fastener Magazine Capacity120
Nail Length15-35 mm
Nail Diameter0.6 mm
Voltage12V
Fastener Gauge23 Ga
Depth AdjustmentYes
Vibration Level (3 axes)≤ 2.5 m/s²
Vibration Uncertainty (K Factor)1.5 m/s²
Product Dimensions (L x W x H):231 x 66 x 226 mm
Sound Pressure Level (LpA)76 dB(A)
Noise Uncertainty (K Factor)3 dB(A)
Battery SystemCXT
Tool weight with battery1.8 - 2.0 kg
Nominal Battery Voltage12 V
Body OnlyYes
Body Only MachineYes
Voltage CXTYes

There are no downloads for this product.
